Značajke
- High speed DSL modem, NAT router and wireless access point in one device providing a one-stop networking solution
- Wireless N speed up to 300Mbps makes it ideal for heavy bandwidth consuming or interruption sensitive applications like online gaming, Internet calls and even the HD video streaming
- Easy Setup Assistant with multi-language support provides a quick & hassle free installation
- SPI and NAT firewall protects end-user devices from potential attacks from the Internet
- WPA-PSK/WPA2-PSK encryptions provide user networks with active defense against security threats
- Easy one-touch WPA wireless security encryption with the WPS button
- Wi-Fi On/Off Button allows users to simply turn their wireless radio on or off
- QoS enables smooth IPTV streaming and lag-free online gaming
- Port VLAN binds specific LAN ports and PVCs for differential services
- Auto-reconnect keeps user online indefinitely
- Backward compatible with 802.11b/g products
Specifikacija
HARDWARE ZNAČAJKE
- Interface:
* 4× 10/100Mbps RJ45 Ports
* 1× RJ11 Port
- Button:
* 1× Power On/Off Switch
* 1× WPS Button
* 1× Wi-Fi On/Off Button
- External Power Supply: 9VDC/0.85A
- IEEE Standards: IEEE 802.3, 802.3u
- ADSL Standards:
* Full-rate ANSI T1.413 Issue 2
* ITU-T G.992.1(G.DMT)
* ITU-T G.992.2(G.Lite)
* ITU-T G.994.1 (G.hs)
* ITU-T G.995.1
- ADSL2 Standards:
* ITU-T G.992.3 (G.dmt.bis),
* ITU-T G.992.4 (G.lite.bis)
- ADSL2+ Standards: ITU-T G.992.5
- Dimensions (W×D×H): 195×130×36 mm
- Antenna Type: Omni directional, Detachable, Reverse SMA
- Antenna Gain: 2×3dBi
WIRELESS ZNAČAJKE
- Wireless Standards: IEEE 802.11b, 802.11g, 802.11n
- Frequency: 2.400 - 2.4835GHz
- EIRP: <20dBm(EIRP)
- Wireless Security:
* Support 64/128 bit WEP, WPA-PSK/WPA2-PSK
* Wireless MAC Filtering
SOFTWARE ZNAČAJKE
- Quality of Service: QoS Remarking based on IPP/ToS, DSCP and 802.1p
- Port Forwarding: Virtual server, DMZ, ACL(Access Control List)
- VPN Pass-Through: PPTP, L2TP, IPSec Pass-through
- ATM/PPP Protocols:
* ATM Forum UNI3.1/4.0
* PPP over ATM (RFC2364)
* PPP over Ethernet (RFC2516)
* IPoA (RFC1577/2225)
* PVC - Up to 8 PVCs
- Advanced Features:
* Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt
* Dynamic Host Configuration Protocol (DHCP), DHCP relay
* Network Address Translation (NAT)
* PVC/Ethernet Port Mapping
* VLAN, 802.1P
* Static Routing, RIP v1/v2 (optional)
* DNS Relay, DDNS
* IGMP snooping V1/2
* IGMP Multicast
* UPnP
- Security:
* NAT Firewall
* SPI Firewall
* MAC / IP / Packet / Application / URL Filtering
* Denial of Service(DoS)
* SYN Flooding
* Ping of Death
- Management:
* Web Based Configuration(HTTP)
* Remote management
* Telnet management
* Command Line Interface
* SSL for TR-069
* SNMP v1/2c
* SNMP over EOC
* Web Based Firmware Upgrade
* CWMP(TR-069)
* Diagnostic Tools
OSTALO
- System Requirements:
* Microsoft Windows 98SE/NT/2000/XP/Vista/7
* MAC OS, NetWare, UNIX or Linux
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
- Operating Humidity: 10% - 90% non-condensing
- Storage Humidity: 5% - 90% non-condensing
- Package Contents:
* TD-W8961NB
* External Splitter
* RJ-11 Telephone Cable
* RJ-45 Ethernet Cable
* Quick Installation Guide
* Resource CD
* Power Adapter
